The CY7C1338G is a 131,072 x 32 synchronous cache RAM designed to interface with high-speed microprocessors with minimum glue logic.
The CY7C1338G is a 4-Mbit (128K x 32) synchronous cache RAM designed to interface with high-speed microprocessors with minimum glue logic. It provides fast clock-to-output times, ranging from 6.5 ns for the 133-MHz version to 8.0 ns for the 100-MHz version. The device supports user-selectable burst counters for Intel Pentium interleaved or linear burst sequences.
| Capacity | 4-Mbit (128K x 32) |
|---|---|
| Core Voltage | 3.3V |
| I/O Voltage | 2.5V or 3.3V |
| Max Access Time (133 MHz) | 6.5 ns |
| Max Access Time (117 MHz) | 7.5 ns |
| Max Access Time (100 MHz) | 8.0 ns |
| Max Operating Current (133 MHz) | 225 mA |
| Max Standby Current | 40 mA |
| Packages | 100-pin TQFP and 119-ball BGA |
It supports user-selectable burst counters for Intel Pentium interleaved or linear burst sequences.
The burst order is determined by sampling the MODE input; HIGH selects interleaved, and LOW selects linear.
The device is available in 133-MHz, 117-MHz, and 100-MHz versions.
