The TZMC series are silicon epitaxial planar Z-diodes manufactured by Vishay Telefunken. It features very sharp reverse characteristic, low reverse current level, available with tighter tolerances, very high stability and low noise.
This document is a datasheet for the Vishay TZMC series of silicon epitaxial planar Z-diodes. It details the product features, such as sharp reverse characteristics and low noise, suitable for voltage stabilization applications. This manual is written in Chinese.
| Junction temperature | 175 °C |
|---|---|
| Storage temperature range | -65...+175 °C |
| Forward voltage (Typ) | 1.5 V |
The device can operate at a maximum junction temperature of 175 °C.
Total power dissipation decreases as the ambient temperature increases, dropping to zero at 200 °C.
