APE1117 is a low dropout positive adjustable or fixed-mode regulator with minimum of 1A output current capability. The product is specifically designed to provide well-regulated supply for low voltage IC applications such as high-speed bus termination and low current 3.3V logic supply. APE1117 is also well suited for other applications such as VGA cards. APE1117 is guaranteed to have lower than 1.4V dropout at full load current making it ideal to provide well-regulated outputs of 1.25 to 5.0 with 6.4V to 12V input supply.
The Advanced Power Electronics APE1117 is a low dropout (LDO) voltage regulator designed for applications requiring well-regulated supplies, such as high-speed bus termination and low-current logic. It supports both adjustable and fixed output modes with available voltages of 1.5V, 1.8V, 1.9V, 2.5V, 3.3V, and 5.0V.
| Output Current Capability | 1A minimum |
|---|---|
| Maximum Dropout Voltage | 1.4V at full load |
| Available Output Voltages | 1.5V, 1.8V, 1.9V, 2.5V, 3.3V, 5.0V |
| Operating Junction Temperature Range | -65 to +150 °C |
The device is available in fixed modes of 1.5V, 1.8V, 1.9V, 2.5V, 3.3V, and 5.0V, or as an adjustable regulator.
The regulator has a maximum dropout of 1.4V at full load current.
