The Samsung M366S1723DTS PC133/PC100 Unbuffered DIMM is a 16M bit x 64 Synchronous Dynamic RAM high density memory module.
The Samsung M366S1723DTS is a high-density 16M bit x 64 Synchronous Dynamic RAM module designed for PC133/PC100 systems. It consists of eight CMOS 16M x 8-bit synchronous DRAMs in TSOP-II packages and includes an EEPROM for Serial Presence Detect (SPD). The module supports operating frequencies up to 133MHz with programmable latencies.
| Memory Capacity | 16M bit x 64 |
|---|---|
| Operating Frequency | Up to 133MHz |
| Supply Voltage | 3.3V + 0.3V |
| Package Type | 168-pin glass-epoxy substrate |
| Refresh Capability | 4096 Cycles/64ms |
The M366S1723DTS-C/L7C and -C/L7A versions operate at a maximum frequency of 133MHz.
The module requires a single power supply of 3.3V plus or minus 0.3V.
The device supports an auto and self-refresh capability with a period of 64ms.
