KPT/KPSE Circular Connectors
The document introduces the KPT and KPSE series from ITT Cannon as miniature circular connectors manufactured according to MIL-C-26482. These connectors feature three-point bayonet coupling and keyway polarization, offering both general-purpose solder contacts and high-performance crimp options suitable for military and industrial applications.
| Coupling Type | Three point bayonet coupling and keyway polarization |
|---|---|
| Operating Temperature | -55 / 125°C |
| Durability (Mating Cycles) | min. 500 mating cycles |
| Vibration Test | 200 mis at 10 to 2000 Hz |
| Contact Rating (AWG 20) | 75 A / less than 55 mV drop |
They conform to MIL-C-26482, NFC 93422 HE 301 model, VG 95328 and LN 29500 specifications.
Yes, all connectors conforming to the mentioned specifications are fully intermateable.
For Service Class 1, the operating voltage is 140 VDC/100 VAC.
