NE56631-XX is a family of Active-LOW system resets that offer precision threshold voltage detection and super low operating supply current.
The NE56631-XX is a family of Active-LOW system reset integrated circuits designed by Philips Semiconductors. It offers high-precision threshold voltage detection within +3% and features super low operating supply currents, typically 1.5 µA. The device includes an internal power-on-reset delay time of typically 20 µs.
| Detection threshold voltage precision | +3% |
|---|---|
| Operating supply current (typical) | 1.5 µA |
| Hysteresis voltage (typical) | 50 mV |
| Output current (LOW Reset) (typical) | 30 mA |
The device can operate at a supply voltage up to +10 V.
It is available in a plastic small outline package with 5 leads (SO-8/SOT23-5).
