The handbook lists the configuration, connector type, cable specifications, thumbscrew size, total length, color and compliance information for the AK‑Y1302 connector assembly. It includes part numbers such as SC3311M and details on the HPDBGBM connector with PIN E.
Physical details note a beige color, a total cable length of 3 FT + 5 CM, and RoHS compliance. The document serves as a quick reference for ordering and installation.
| Connector | HPDBGBM, PIN E |
|---|---|
| Thumbscrew | 42‑56 UNC |
| Cable | #28, UL2919, 25P‑+1+AL/MY+8, 0.0:9,5(1,0:0,75mm) |
| Color | Beige |
| RoHS Compliance | Compliant |
The part number is SC3311M.
Yes, it is RoHS compliant.
The connector is beige.
