This document introduces the technical information of PUA3213, PUB4213, PUB4513 three power transistor array products produced by Panasonic, including product characteristics and application circuits.
This datasheet provides the new Panasonic part numbers for three power transistor arrays—PUB4513, PUA3213, and PUB4213—and lists their key electrical characteristics, package information, and thermal performance. It also includes a naming conversion table that maps the legacy part numbers to the current Panasonic unified numbers.
The document contains detailed specifications such as collector‑emitter voltage limits, maximum power dissipation, transition frequency, and recommended heat‑sink configurations. It concludes with important usage notes, export restrictions, and warranty information for designers using these devices in standard electronic applications. This manual is written in Japanese.
| Maximum collector‑emitter voltage (Vcbo) | 100 V |
|---|---|
| Maximum power dissipation (Pp) | 15 W |
| Collector saturation voltage (Vcgo) | -0.130 V |
The new Panasonic unified part numbers are PUB4513, PUA3213, and PUB4213.
The maximum power dissipation is 15 W.
