74LVC86A is a low-voltage, low-power CMOS logic chip produced by Philips Semiconductors. It has a wide power supply range of 1.2V to 3.6V, supports 5.5V input voltage, and can also be used as a decoder in a mixed 3.3V/5V power supply environment.
The 74LVC86A is a quad 2‑input exclusive‑OR gate implemented in a low‑power, low‑voltage CMOS process. It offers a wide supply range and TTL‑compatible inputs, making it suitable for mixed‑voltage designs.
The datasheet lists electrical parameters such as supply voltage, propagation delay, and power dissipation, as well as mechanical data for several package options (DIP, SOT, SSOP, TSSOP). Recommended operating conditions, absolute maximum ratings, and temperature limits are also included.
| Supply voltage range | 1.2 V to 3.6 V |
|---|---|
| Maximum input voltage | 5.5 V |
The device operates from 1.2 V up to 3.6 V.
Inputs can tolerate voltages up to 5.5 V.
