KA2004-BE51A thermal printhead is a product developed by ROHM that is suitable for mobile printers, EFT-POS terminals, handheld printers, and debit printers. The product has low power consumption and high integration, which can meet the needs of mobile devices for battery life.
The KA2004-BE51A thermal printhead is designed for mobile printers, EFT‑POS terminals, hand‑held printers and other compact devices. It operates on a single lithium‑ion battery with a low supply voltage, enabling miniaturized end products.
Key features include a reduced protective resin height, enlarged paper pathway, and low energy consumption. The document lists dimensions, pin assignments, timing charts, and detailed electrical characteristic curves to aid circuit design and integration. This manual is written in Chinese.
| Print voltage | 2.7 V |
|---|---|
| Maximum supply voltage | < 8.5 V |
| Effective print width | 117 mm |
The printhead operates at a print voltage of 2.7 V.
It can be driven with a supply voltage of less than 8.5 V.
The effective print width is 117 mm.
