kd2003-cg10a printhead is suitable for high-end pos terminals and label printers that require higher printing speeds. it adopts a special compact partial glaze and new heating element structure to achieve high-speed printing at 150 mm/s.
The KD2003-CG10A is a compact medium‑speed thick‑film thermal printhead designed for high‑speed POS terminals, label printers, and other small‑sized printers. It offers a resolution of 8 dots/mm and can print at speeds up to 150 mm/s, making it suitable for demanding printing applications.
Key features include a highly durable conductive protective film, reinforced VH and GND power sections, ultra‑small FFC connectors, a uniform resistance of 800 Ω ± 3 %, a wide driving voltage range of 3.15‑5.25 V, and three size options (2‑inch, 3‑inch, 4‑inch). The printhead can accommodate platens up to 20 mm in diameter and provides detailed electrical characteristic curves for design reference.
| Resolution | 8 dots/mm |
|---|---|
| Maximum printing speed | 150 mm/s |
| Driving voltage range | 3.15 V – 5.25 V |
| Available sizes | 2‑inch, 3‑inch, 4‑inch |
| Maximum platen diameter | 20 mm |
It can print at speeds up to 150 mm/s.
The required driving voltage is between 3.15 V and 5.25 V.
It is offered in 2‑inch, 3‑inch, and 4‑inch series.
