G5CA is a power relay from OMRON, with rated voltage options of DC5V, DC12V, DC24V, AC110V, AC250V, and a maximum current of 15A and a maximum switching capacity of 500V/10A.
This service manual provides detailed information for the Omron G5CA series power relays, including electrical ratings, mechanical dimensions, and environmental limits. It also lists the various coil voltage options and contact configurations for different model variants.
Installation guidelines, mounting recommendations, and certification data (UL, CSA, EN) are included to help technicians correctly integrate the relay into heating, industrial, or appliance applications. This manual is written in Chinese.
| Rated contact current | 10 A |
|---|---|
| Physical size | Height 11 mm, Width 22 mm, Length 16 mm |
It is certified to UL (file No. E41515) and CSA (file No. LR31928) standards.
