This document is an introduction to the reference data and performance characteristics of the G2RG series AC resistive load relays. The relay has a 2a contact configuration, a coil rated voltage of 12V and 24V, a maximum allowable voltage of 140%, and a power consumption of approximately 800mW. It has good insulation performance and withstand voltage capability, and meets the requirements of European UPS. It is suitable for household appliances, OA equipment, and FA equipment.
This service manual describes the G2RG series power relay, including its mechanical dimensions, contact configuration, and compliance with European UPS standards. It lists key electrical parameters such as coil voltage, contact rating, and insulation requirements, and provides certification information for UL, CSA, and EN standards.\n\nThe document also includes wiring diagrams, environmental limits, and recommended testing procedures for contact resistance, durability, and impact voltage. Users are instructed to verify specifications before installation and to follow the outlined maintenance steps to ensure reliable operation. This manual is written in Chinese.
| Contact spacing | 3 mm |
|---|---|
| Withstand voltage | 10 kV |
| Coil voltage | 24 V DC |
| Contact rating | 250 V AC, 8 A |
| Electrical life | > 1,000,000 cycles |
| Operating temperature | -40 °C to +70 °C |
| Humidity range | 5%–85% RH |
| Weight | ≈17.2 g |
| Contact resistance | < 100 mΩ |
The coil is rated for 24 V DC.
The contacts are rated for 250 V AC at 8 A.
It can operate from –40 °C up to +70 °C.
The relay is certified to UL, CSA, and EN (VDE) standards.
