This document describes the features and characteristics of the 3G M B-330 G3M solid state relay, including its slim shape, high-density packaging, DC input-AC output, and the ability to handle loads of 3A and 5A.
The Omron G3M series relays are compact, 5 A type devices designed for printed‑circuit‑board mounting. They are offered with three input voltage options (DC 5 V, DC 12 V, DC 24 V) and are certified to UL, CSA and EN standards.
This service manual provides electrical ratings, mechanical dimensions, environmental specifications, and wiring diagrams for the G3M‑203P and G3M‑205P models, along with handling and storage guidelines. This manual is written in Chinese.
| Maximum load current | 5 A |
|---|---|
| Weight | ≈15 g (G3M‑203P), ≈25 g (G3M‑205P) |
The series is rated for a maximum load current of 5 A.
