G7L series power relays use high-voltage, high-surge voltage drop performance lines and have high capacity, high reliability and other characteristics. It can be applied to various loads, such as air conditioner compressors, electric tools, water heaters, dryers, OA equipment, lighting, packaging machines, food processing equipment, microwave ovens, etc.
This service manual provides detailed information for Omron G7L series power relays, including model variants, electrical specifications, and safety features. It is intended for technicians who need to install, test, and maintain these relays in industrial equipment.
The document contains sections on model structure, performance parameters, environmental and voltage‑drop tests, load‑life testing, mounting options, and accessory part numbers. Technical drawings and dimension tables are included for each relay variant. This manual is written in Chinese.
| Maximum Contact Current | 30 A |
|---|---|
| Contact Spacing | 3 mm |
| Flame‑Retardant Insulation | UL94V‑0 |
The G7L series can handle a maximum contact current of 30 A.
All insulation materials comply with the UL94V‑0 flame‑retardant standard.
The relay features a 3 mm contact spacing for safety.
