GA-X79-UD7 User's Manual, introduces the detailed information of the motherboard, including the layout of the motherboard, installation steps, and usage methods.
This manual covers all aspects of the GA‑X79‑UD7 motherboard, including hardware installation, BIOS configuration, driver setup, and troubleshooting. It also lists regulatory compliance and safety standards.
The document includes a detailed layout diagram, block diagram, step‑by‑step installation procedures for CPU, memory and expansion cards, BIOS feature explanations, driver download guidance, and an appendix with SATA and audio configuration details.
| CPU socket | LGA2011 |
|---|---|
| Supported memory | DDR3 2133/1866/1600/1333/1066 MHz |
| Memory channels | 4‑Channel |
| USB ports | 2 × USB 3.0/2.0 |
| LAN controller | Intel® GbE LAN |
The revision number appears as "REV: X.X", for example "REV: 1.0".
