GA-G41MT-D3P is a motherboard from GIGABYTE, which supports Intel® Core™ i3/i5/i7/Pentium®/Celeron® processors.
This manual provides step‑by‑step instructions for installing the GA‑G41MT‑D3P and GA‑G41MT‑S2P motherboards, including CPU, memory, and expansion‑card installation, as well as detailed safety precautions such as power‑off procedures and antistatic handling.
It also lists the technical specifications of the boards – supported CPUs, chipset, memory capacity, connectors, and BIOS features – and explains how to use the BIOS, clear CMOS, and replace the battery. This manual is written in German.
| Supported CPUs | Intel® Core™ 2 Extreme, Core™ 2 Quad, Core™ 2 Duo, Pentium, Celeron (LGA775) |
|---|---|
| Chipset | Intel G41 Express (North Bridge) / Intel ICH? (South Bridge) |
| Memory Slots | 2 x 1.5 V DDR3 DIMM slots |
| Maximum Memory | Up to 8 GB system memory |
| Front Side Bus | 1333/1066/800 MHz |
| LAN | Atheros AR8151 Gigabit Ethernet (10/100/1000 Mbit) |
| SATA Ports | 4 SATA ports, 3 GB/s each |
| USB Ports | Up to 8 USB 2.0/1.1 ports (4 rear, 4 internal) |
| Form Factor | Micro ATX, 24.4 cm × 19.4 cm |
Always disconnect the computer from the mains, wear an antistatic wrist strap or touch a metal object, avoid touching circuitry, and keep screws away from the board.
The board uses an LGA775 socket for Intel® Core™, Pentium®, and Celeron® processors.
