GA-H61M-USB3-B3 is a motherboard with features such as CPU installation, memory installation, and expansion card installation. The motherboard has a REV: 1.0 version. This document contains the hardware installation instructions, product specifications, and connector information of the motherboard.
This manual provides step‑by‑step hardware installation instructions, BIOS configuration guidance, and driver installation procedures for the Gigabyte GA-H61M-USB3-B3 motherboard. It also includes regulatory statements, product specifications, and contact information for technical support.
The document contains detailed diagrams of the motherboard layout, a full list of connectors and slots, and safety precautions such as ESD handling and power‑off requirements before installation.
| CPU Socket | LGA1155 |
|---|---|
| Chipset | Intel H61 Express |
| USB Ports | Up to 2 USB 3.0/2.0 ports, up to 6 USB 2.0/1.1 ports |
It provides up to two USB 3.0/2.0 ports on the back panel.
The board uses an LGA1155 socket.
There are two SATA 6 Gb/s connectors.
