This is a PDF file about the PTSA 0,5/16-2,5-Z product. This product is produced by PHOENIX CONTACT company. The rated current is 2A, the rated voltage is 160V, the pin spacing is 2.5mm and the product color is green.
The PTSA 0.5/16-2.5-Z is a 10‑position spring‑cage terminal block from Phoenix Contact. It is designed for 2 A nominal current and 160 V nominal voltage, with a 2.5 mm pitch and 16 positions.
The document provides detailed technical data, dimensional drawings, derating diagrams and certification information, extracted from the online Phoenix Contact catalog.
| Nominal current | 2 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 2.5 mm |
| Number of positions | 16 |
| Type of connection | Spring‑cage |
| Conductor/PCB connection direction | 45° |
| Color | green |
| Weight per piece | 0.006146 kg |
The terminal block is rated for a nominal current of 2 A.
The pitch is 2.5 mm.
It provides 16 positions.
It uses a spring‑cage connection.
