This document introduces the PCV 4/3-G-7.62 product produced by Phoenix Contact GmbH & Co. KG. The product features a rated current of 20A, rated voltage of 400V, pitch of 7.62mm, 3 positions, green color, and soldering assembly.
The PCV 4/3-G-7.62 is a 5‑position, green‑colored terminal block with a 7.62 mm pitch, rated for 20 A and 400 V. It complies with EN‑VDE standards and offers a range of certifications including BV, CSA and UL. Technical data such as surge voltage, insulating material and weight are listed.
The document also lists compatible accessories, mounting options, and packaging details. Contact information for Phoenix Contact Germany is provided for further inquiries.
| Nominal current | 20 A |
|---|---|
| Nominal voltage | 400 V |
| Pitch | 7.62 mm |
| Number of positions | 3 |
| Color | green |
| Rated surge voltage (III/3) | 6 kV |
| Insulating material group | I |
| Weight per piece | 0.00619 kg |
The connector is rated for a nominal current of 20 A.
The pitch is 7.62 mm.
It has three positions.
It is certified BV, CSA, CUL, DNV, GL, GOST, LR, RS and UL.
