This document provides information about the MDSTB 2.5/4-G1-5.08 product from PHOENIX CONTACT GmbH & Co. KG. The product is a 10-position connector with a nominal current of 10A and a nominal voltage of 250V. It has a pitch of 5.08mm and is green in color. The connector can be soldered for assembly.
The MDSTB 2,5/4-G1-5,08 is a 4‑position green terminal block with a 5.08 mm pitch, designed for DIN‑rail mounting. It is rated for 10 A nominal current and 250 V nominal voltage, with a soldering assembly option.
The document provides dimensions, weight, EAN code, compliance information, and a list of compatible accessories and additional product variants. Contact details for Phoenix Contact and download links are also included.
| Nominal current | 10 A per position |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5.08 mm |
| Number of positions | 4 |
| Color | green |
| Assembly type | Soldering |
| Dimension a | 15.24 mm |
| Weight per piece | 0.00844 kg |
| EAN | 4017918027872 |
| RoHS compliance date | 01/01/2003 |
The terminal block is rated for 10 A nominal current per position.
The pitch is 5.08 mm.
It has four positions.
The terminal block is green.
