5-position plug connector with screw connection for connection of wires and cables up to 30.48 mm in diameter.
This handbook describes the PC 4 HV series terminal block with a 5‑position, 7.62 mm pitch design. It lists the electrical ratings, mechanical dimensions, and connection details required for proper installation.
The document also includes certification information, recommended tightening torques, and a list of compatible accessories such as marker cards, screwdriver tools, and derating curves.
| Nominal current | 20 A |
|---|---|
| Nominal voltage | 800 V |
| Pitch | 7.62 mm |
| Number of positions | 5 |
| Connection type | Screw connection |
| Weight per piece | 0.02232 kg |
The terminal block is rated for a nominal current of 20 A.
It has five positions.
The pitch is 7.62 mm.
A minimum torque of 0.5 Nm and a maximum torque of 0.6 Nm are recommended.
