P4i65G is a motherboard that supports Intel Pentium 4 / Celeron D processors. It features the Intel 865G chipset, supports FSB800/533MHz processors and H-T hyper-threading technology. In addition, it also has dual-channel DDR400 memory technology, AGP 8X slot, integrated Intel Extreme Graphics 2 display core, Hybrid Booster safe overclocking technology, and more.
This manual describes the ASRock P4i65G Micro‑ATX motherboard, its supported Intel Pentium 4/Celeron D processors, dual‑channel DDR400 memory, and integrated Intel Extreme Graphics 2. It includes details on the board layout, expansion slots, audio, networking, and power connectors.
The document also covers BIOS features, hardware monitoring (CPU/ chassis temperature, voltage), the Hybrid Booster over‑clocking technology, and the included accessories such as the quick‑install guide, CD, and I/O shield. This manual is written in Chinese.
| Form factor | Micro ATX 9.6" x 7.8" |
|---|---|
| CPU socket | Socket 478 |
| Front Side Bus | 800 MHz / 533 MHz |
| Memory slots | 2 x DDR400 (max 2 GB) |
| Maximum memory capacity | 2 GB |
| AGP slot | 1 x AGP 8X |
| PCI slots | 3 x PCI |
| SATA ports | 2 x Serial ATA 1.5 Gb/s |
| IDE ports | 2 x ATA100 IDE |
| Integrated graphics | Intel Extreme Graphics 2, DirectX 8.0 support |
| Audio codec | Cmedia 9761A 5.1‑channel |
| LAN controller | Realtek PCI‑LAN 8101L, 10/100 Mbps |
| USB ports | 6 x USB 2.0 |
It supports Intel Pentium 4 and Celeron D processors, including the Prescott, Northwood, and Willamette families.
