This is a 3-port physical layer interface IC that supports 100Mb/s and 200Mb/s transfers, is compatible with any 1394 standard Link Layer Controller, supports 5V voltage, and supports single 3.3V power supply.
The PDI1394P11A is an IEEE‑1395‑1995 compliant physical‑layer IC that provides three 1394 cable ports, bus initialization, arbitration and line‑condition monitoring. It operates from a single 3.3 V supply and is compatible with both 3 V and 5 V link‑layer controllers.
The device is supplied in a 64‑pin plastic LQFP package, works from 0 °C to +70 °C, and offers a nominal 1.85 V bias for cable termination. Detailed electrical limits, timing parameters and pin functions are provided for designers.
| Supply voltage (Vop) | 3.3 V typical, 3.6 V max |
|---|---|
| Maximum data rate | 200 Mb/s |
| Package type | 64‑pin plastic LQFP (LOFP64) |
| Operating temperature range | 0 °C to +70 °C |
| Bias voltage for cable termination | 1.85 V nominal |
It can transmit at up to 200 Mb/s while remaining compatible with 100 Mb/s devices.
The IC is offered in a 64‑pin plastic LQFP (LOFP64) package.
The device is specified for operation from 0 °C to +70 °C.
It runs from a single 3.3 V supply, with a maximum of 3.6 V allowed.
