SA56614-XX is a CMOS device designed to generate a reset signal for a variety of microprocessor and logic systems. Accurate reset signals are generated during momentary power interruptions, or whenever power supply voltages sag to intolerable levels.
The SA56614-XX is a CMOS reset IC from Philips Semiconductors designed to generate a reliable reset signal during power interruptions or voltage sags. It offers a totem‑pole output, low operating voltage options and multiple reset‑threshold versions for microprocessor and logic applications.
The device is supplied in a SOT23‑5 surface‑mount package and includes specifications such as a 12 V maximum supply, 50 mA output current and operation over –40 °C to 85 °C. Detailed pin configurations, maximum ratings and timing diagrams are provided for designers.
| Maximum supply voltage (Vop) | 12 V |
|---|---|
| Output current (Iout) | 50 mA |
| Operating temperature range | -40 °C to 85 °C |
| Storage temperature range | -40 °C to 125 °C |
| Power dissipation | 150 mW |
| Typical supply current | 0.25 µA |
| Package | SOT23‑5 surface‑mount |
The device can operate with a supply voltage up to 12 V.
It is available in a SOT23‑5 surface‑mount package.
The SA56614‑XX typically draws 0.25 µA of supply current.
