The HD74LVC125A is a device with four bus buffer gates, suitable for low voltage and high speed operation. Its features include low power consumption, high output current, and high impedance state control.
The HD74LVC125A is a quad bus buffer gate with 3‑state outputs offered in a 14‑pin package. The document details its functional description, pin arrangement, absolute maximum ratings, and recommended operating conditions for low‑voltage, high‑speed applications.
Key sections include electrical characteristics such as supply voltage limits, output current capability, propagation delay, and switching characteristics, as well as test circuits, waveform examples, mechanical dimensions, and legal cautions regarding use and intellectual property.
