LNW9B2BZFZ round light emitting diode product information, including maximum working voltage, maximum working current, luminous color and other characteristics
The LNW9B2BZFZ is a 5.0 mm blue surface‑mount LED manufactured by Panasonic. The sheet lists its part numbers, lighting color, and mechanical dimensions.
Key electrical parameters include a typical forward voltage of 3.7 V, a typical wavelength of 460 nm, a maximum forward current of 20 mA, and a duty cycle of 10 % for pulse operation. Absolute maximum ratings and electro‑optical characteristics are also detailed.
| Part Number | LNW9B2BZFZ |
|---|---|
| Lighting Color | Blue |
| Duty Cycle (pulse) | 10 % |
| Maximum Power | 120 mW |
The duty cycle is 10 % for pulse operation.
