DVK90CAN1 is a development board that can be used to develop AT90CAN128 microcontroller. This manual describes the features of the development board, its use and how it is used in the system.
This guide introduces the DVK90CAN1 – an AT90CAN128 development kit designed for rapid prototyping and testing. It describes the board’s features, power‑supply options, on‑board resources such as LEDs, keyboard, sensors, and multiple serial interfaces, and how to integrate the kit with an Atmel STK500 starter board.
The document includes detailed sections on unpacking, system requirements, quick start, block diagram, power‑supply configuration, programming, debugging, test points, a basic test program, troubleshooting, full technical specifications, and complete schematics with a bill of materials.
| Physical dimensions | L=119 x W=56 x H=27 mm |
|---|---|
| Weight | 60 g |
| Operating voltage | 2.7 V – 5.5 V |
| RS‑232C connector | 9‑pin D‑SUB female |
| RS‑232C max speed | 250 kbps |
| CAN max speed | 1 Mbps |
| LIN max speed | 9600 bps |
| SPI max speed | 4 Mbps |
| TWI max speed | 400 kbps |
The board operates from 2.7 V to 5.5 V.
The VCC‑ON LED lights when the board’s power supply is active.
