Vishay VLMF31.. LED Datasheet

This document is the Vishay Semiconductors VLMF31.. SMD PLCC-2 High Intensity LED datasheet, introducing the features and characteristics of the product.

Brand: Vishay
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 8
File format: PDF
File size: 174 KB
Published: 08 May, 2012
Updated: 30 September, 2023
Model: VLMF31
MD5 checksum: 35C183A31809C50FAFB86BA5AB44CAC9
PDF: Vishay VLMF31.. LED Datasheet PDF

About this manual

The VLMF31.. series is a high‑intensity SMD LED offered by Vishay Semiconductors in a PLCC‑2 package. It provides bright soft‑orange light, low power consumption, and is compatible with automatic placement equipment.

The document details electrical and optical characteristics, absolute maximum ratings, packaging dimensions, tape‑and‑reel handling, recommended soldering profiles, and storage precautions for moisture‑sensitive devices.

What's inside

Description
Product Group and Package Data
Applications
Absolute Maximum Ratings
Optical and Electrical Characteristics
Typical Characteristics
Package Dimensions
Method of Taping/Polarity and Tape and Reel
Ozone Depleting Substances Policy
Disclaimer

Specifications

Junction temperature (Tj)	125 °C
Operating temperature range	-40 °C to +100 °C
Storage temperature range	-40 °C to +100 °C

Frequently asked questions

What soldering profile is recommended for the VLMF31.. LED?

A lead‑free reflow soldering profile according to J‑STD‑020C is recommended.
