The GMF05LC-HS3 is a 5-line ESD protection diode array from Vishay Semiconductors, packaged in LLP75-6A. It features a low leakage current IR <0.1 µA, low load capacitance of typ. 43 pF, ESD immunity of ±30 kV contact discharge and ±30 kV air discharge. The working voltage range is VRWM = 5 V. The device complies with RoHS 2002/95/EC and WEEE 2002/96/EC.
The GMFO5LC-HS3 is a 5‑line ESD‑protection diode array offered in an ultra‑compact LLP75‑6A package. It provides bidirectional asymmetrical protection for up to five signal or data lines, with low leakage current and low load capacitance.
The document includes ordering information, package dimensions, absolute maximum ratings, electrical characteristics, typical performance curves, and compliance statements (RoHS, lead‑free, non‑magnetic).
| Package type | LLP75-6A |
|---|---|
| Lead‑free | Yes |
| RoHS compliance | Yes |
| Working voltage range | 5 V |
| Load capacitance (typ.) | 43 pF at Va=0 V |
| Maximum protected lines | 5 lines |
It can protect up to five signal or data lines.
The typical load capacitance is 43 pF at a voltage of 0 V.
The device operates with a working voltage of 5 V.
Yes, it complies with RoHS 2002/95/EC and WEEE 2002/96/EC.
