TD-8811/TD-8811B is a TP-LINK ADSL2+ router that supports the latest ADSL2/2+ standards for speeds up to 24Mbps downstream and 3.5Mbps upstream. It also features 1 10/100 Ethernet port and 1 USB port, and a built-in QoS engine to help prioritize Internet traffic.
The TP‑Link TD‑8811/TD‑8811B is a 2‑in‑1 ADSL2+ router that combines a DSL modem with a 10/100 Mbps Ethernet and USB 1.1 router. It supports ADSL2/2+ standards for up to 24 Mbps downstream and 3.5 Mbps upstream (Annex M) and includes QoS, dual‑firewall, and VPN pass‑through to prioritize VoIP, gaming, and streaming.
The device offers one RJ11 line port, one 10/100 Mbps Ethernet port, and one USB 1.1 port. It provides static routing, NAT, DHCP server, UPnP, and SNMP management. Operating temperature ranges from 0 °C to 40 °C, with storage limits of –40 °C to 70 °C, and dimensions of 6.5 × 4.3 × 1.1 in.
| Downstream data rate | Up to 24 Mbps |
|---|---|
| Upstream data rate | Up to 3.5 Mbps (Annex M enabled) |
| RJ11 ports | 1 |
| Ethernet ports | 1 (10/100 Mbps) |
| USB ports | 1 (USB 1.1) |
| Dimensions (L × W × H) | 6.5 × 4.3 × 1.1 in (165 × 108 × 28 mm) |
| Operating temperature | 0 °C ~ 40 °C (32 °F ~ 104 °F) |
| Storage temperature | -40 °C ~ 70 °C (-40 °F ~ 158 °F) |
| Operating humidity | 10 % ~ 90 % RH non‑condensing |
| Storage humidity | 5 % ~ 90 % RH non‑condensing |
The router supports downstream speeds of up to 24 Mbps.
It includes one 10/100 Mbps Ethernet port.
Yes, QoS enables smooth VoIP, video streaming, and lag‑free online gaming.
Yes, SNMP V1/V2 is supported for centralized management.
