The 108Mbps Wireless Router Tl-WR642G is dedicated to Small Office/Home Office (SOHO) Wireless network solutions. It integrates the functions of Wireless Access Point, firewall, 4-port Switch and NAT-Router. It helps you set up a wired or wireless network, lets your computers share a high-speed DSL or Cable Internet connection, data files and other resources such as printers and hard disk storage space. The TL-WR642G complies with the IEEE 802.11g/b standards. In addition, it adopts 108 M Super G™ WLAN transmission technologies to support data transmission rates up to 108Mbps. It also adopts 2x to 3x eXtended Range™ WLAN transmission technology so that transmission distance is 2-3 times that of traditional 11g/b solutions, transmission range is extended to 4-9 times. It is compatible with all IEEE 802.11g and IEEE 802.11b products. With easy-to-use Quick Setup Wizard and plenty of functions, the TL-WR642G is your best choice to create a secure wireless network easily for your home and small office.
The TL-WR642G is a 108Mbps wireless router designed for small office/home office (SOHO) environments. It combines a wireless access point, firewall, 4‑port switch, and NAT router, allowing wired or wireless networking, internet sharing, and resource access such as printers and storage.
The manual includes a Quick Setup Wizard for easy configuration, details on supported standards (IEEE 802.11g/b), Super G™ technology, extended range, security options, and full specifications of interfaces, antenna, power supply, and environmental limits.
| Wireless Standards | IEEE 802.11g/b |
|---|---|
| Interface | 1 10/100M auto‑sensing RJ45 Port (Auto MDI/MDIX) |
| Maximum Wireless Data Rate | 108 Mbps (Super G™) |
| Frequency Range | 2.4‑2.4835 GHz |
| Wireless Transmit Power | 17 dBm (max) |
| Antenna | 3 dBi detachable omni‑directional antenna |
| Power Supply | 9 VAC / 0.8 A linear PSU |
| Operating Temperature | 0 °C ~ 40 °C |
| Storage Temperature | -40 °C ~ 70 °C |
| Dimensions | 174 mm × 111 mm × 30 mm |
Use the built‑in Quick Setup Wizard, which guides you through basic configuration steps.
It complies with IEEE 802.11g and IEEE 802.11b standards.
The router provides up to 108 Mbps using Super G™ technology.
