TP-LINK’S TL-POE10R PoE Receiver Adapter is a cost-saving and safe PoE adapter that fully complies with IEEE 802.3af standard, and can supply power and data for non-PoE devices, such as Wireless Access Points, IP Cameras or IP Phones, through an Ethernet cable. It supports 5V or 12V output power switching.
The TL-POE10R PoE Receiver Adapter complies with IEEE 802.3af and allows you to receive power and data from any PoE‑compatible Power Source Equipment, then split them into separate power and data cables for non‑PoE devices such as wireless access points, IP cameras, or IP phones. It supports auto‑sensing, short‑circuit protection, and plug‑and‑play installation.
Key features include an adjustable 5 VDC or 12 VDC output selectable via a slide switch, up to 11.5 W (5 V) or 12 W (12 V) power delivery, and standard RJ45 ports for PoE input and LAN output. The device operates within a temperature range of –40 °C to 40 °C and meets FCC and CE safety standards.
| PoE Input Port | 1 10/100M Auto‑Negotiation RJ45 PoE port |
|---|---|
| LAN Output Port | 1 10/100M Auto‑Negotiation RJ45 LAN port |
| Power Socket | 1 DC output socket |
| Supported Standards | IEEE 802.3af, 10Base‑T, 100Base‑TX |
| Adjustable Output Voltage | 5 VDC or 12 VDC selectable |
| Maximum Power Delivery | 11.5 W at 5 VDC, 12 W at 12 VDC |
| Dimensions (W×D×H) | 3.2 × 2.0 × 0.9 in (81 × 52 × 24 mm) |
| Operating Temperature | 0 °C to 40 °C |
| Storage Temperature | -40 °C to 70 °C |
The adapter provides an adjustable output of either 5 VDC or 12 VDC, selectable with a slide switch.
It can supply up to 11.5 W at 5 VDC or up to 12 W at 12 VDC.
No configuration is needed; the device is plug‑and‑play.
