The SGE2000 is a 24-port 10/100/1000 Gigabit Ethernet switch with 4 shared SFP slots and stacking capabilities. It offers fully redundant stacking, redundant power options, and dual images for resilient firmware upgrades to maximize system availability. The SGE2000 is able to secure the network through IEEE 802.1Q VLANs, IEEE 802.1X port authentication, Access Control Lists (ACL), DOS prevention, and MAC-based filtering. Enhanced QoS and traffic management features ensure clear and reliable voice and video communications. The SGE2000 Switch includes an intuitive, secure management interface that enables you to better utilize the comprehensive feature-set of the SGE2000, resulting in a better optimized, more secure network.
The SGE2000 provides 24 RJ‑45 10/100/1000 Mbps ports plus four shared Gigabit SFP slots for fiber expansion. It supports fully redundant stacking, dual‑image firmware upgrades, and optional redundant power supply for high availability. Advanced security includes IEEE 802.1X authentication, ACLs, DOS protection and MAC‑based filtering, while QoS and traffic management ensure reliable voice and video communications.
Management is performed via a web‑based interface with SSH/SSL support, and the switch integrates with Linksys One Ready for automatic discovery and configuration. The device meets UL, CSA, CE and FCC certifications and is designed for rack‑mount deployment.
| Ports | 24 RJ‑45 connectors + 4 shared SFP slots |
|---|---|
| Switching Capacity | Up to 48 Gbps, non‑blocking |
| Power Consumption | 12 V @ 7.5 A (90 W) |
| Dimensions | 17.32" × 14.70" × 1.73" (440 × 375 × 44 mm) |
| Weight | 14.09 lb (6.39 kg) |
| Fans | 2 |
| Stacking Capacity | Up to 8 units (192 ports) |
It has 24 10/100/1000 Mbps Ethernet ports.
The switch can handle up to 48 Gbps of non‑blocking traffic.
Yes, it can be connected to a Redundant Power Supply unit (RPS1000).
Up to eight units can be stacked, providing 192 ports in total.
