Linksys 16-Port 10/100 Switch is a Gigabit Switch with 16 10/100 full-duplex ports, Autosensing, Auto MDI/MDI-X ports, compatible with all MSTP network equipment.
The SR216 is a 16‑port 10/100 Ethernet switch designed for rack‑mount or desktop installation. It offers auto‑sensing ports, full‑duplex operation, auto MDI/MDI‑X, address learning, and data‑flow control for reliable network performance.
The manual covers installation options, including desktop, wall‑mount, and rack‑mount configurations, and lists detailed technical specifications such as port count, switching speed, dimensions, power requirements, and environmental ratings.
| Ports | 16 10/100 RJ-45 |
|---|---|
| Maximum Switching Speed | up to 200 Mbps full‑duplex |
| Auto MDI/MDI‑X | Supported on each port |
| Dimensions | 279.4 mm × 44.5 mm × 240 mm (11.00" × 1.75" × 9.45") |
| Weight | 3.3 lbs (1.5 kg) |
| Power Input | 110 VAC, Output 16.5 W |
| Operating Temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Certifications | FCC Class B, CE |
It has 16 10/100 RJ‑45 ports.
The switch can operate up to 200 Mbps in full‑duplex mode.
Yes, each port supports auto MDI/MDI‑X cable detection.
The unit measures 279.4 mm × 44.5 mm × 240 mm (11.00" × 1.75" × 9.45").
