The 74AC11086 is a quadruple 2-input exclusive-OR gate chip produced by Texas Instruments. It uses a 1-µm EPIC process and has a typical current-pull-down capability of 500mA. It operates over a temperature range of -40°C to 85°C.
The 74AC11086 contains four independent 2‑input exclusive‑OR gates that implement the Boolean function Y = A⊕B = A·B̅ + A̅·B. It is intended for use as a true/complement element and operates over a temperature range of –40 °C to 85 °C.
The document lists recommended operating conditions, absolute‑maximum ratings, and detailed electrical parameters such as supply voltage, input/output voltage ranges, and continuous output current. Packaging options include Plastic Small‑Outline (SOIC) and standard 300‑mil DIP packages, with mechanical drawings and tape‑and‑reel dimensions provided.
| Supply voltage range | 3 V – 5.5 V |
|---|---|
| Maximum power dissipation (D package) | 1.3 W |
| Operating temperature range | –40 °C to 85 °C |
Each gate implements Y = A⊕B = A·B̅ + A̅·B.
The recommended supply voltage is 3 V to 5.5 V.
Available packages are Plastic Small‑Outline (SOIC) and standard 300‑mil DIP.
