The bq24610 is a highly integrated, low quiescent current synchronous switch mode battery charge controller. It supports 1-6 cell battery strings, input voltage range of 5V-28V, and maximum 10A charge current and 10A adapter current.
The bq24610 and bq24617 are stand‑alone synchronous switch‑mode battery charger controllers for Li‑Ion and Li‑Polymer cells. They support 1‑6 cells (bq24610) or 1‑5 cells (bq24617) and are intended for netbooks, handheld terminals, industrial and medical equipment, and other portable devices.
Key specifications include a 5 V to 28 V input voltage range, up to 10 A charge current, low off‑state discharge current (<1.5 mA), and a compact 24‑pin 4×4 mm QFN package. The datasheet provides detailed pin‑out, absolute maximum ratings, recommended operating conditions, and thermal data for designers.
| Input voltage range | 5 V to 28 V |
|---|---|
| Maximum charge current | Up to 10 A |
| Package type | 24‑pin 4×4 mm QFN |
The device operates with an input voltage from 5 V up to 28 V.
The bq24610 supports 1 to 6 Li‑Ion or Li‑Polymer cells.
Both devices can deliver up to 10 A of charge current.
