MAX9400/MAX9402/MAX9403/MAX9405 are extremely fast, low-skew quad LVECL/ECL or LVPECL/PECL buffer/receivers designed for high-speed data and clock driver applications. These devices feature an ultra-low propagation delay of 335ps and channel-to-channel skew of 16ps in asynchronous mode with 86mA supply current. The four channels can be operated synchronously with an external clock, or in asynchronous mode determined by the state of the SEL input. An enable input provides the ability to force all the outputs to a differential low state. A variety of input and output terminations are offered for maximum design flexibility. The MAX9400 has open inputs and open emitter outputs. The MAX9402 has open inputs and 50Ω series outputs. The MAX9403 has 100Ω differential input impedance and open emitter outputs. The MAX9405 has 100Ω differential input impedance and 50Ω series outputs. These devices operate with a supply voltage of (VCC - VEE) = 2.375V to 5.5V, and are specified for operation from -40°C to +85°C. These devices are offered in space-saving 32-pin 5mm ✕ 5mm TQFP and 32-lead 5mm ✕ 5mm QFN packages.
The MAX9400, MAX9402, MAX9403, and MAX9405 are ultra‑fast, low‑skew quad LVECL/ECL or LVPECL/PECL buffer/receivers designed for high‑speed data and clock driver applications. They feature a propagation delay of 335 ps, channel‑to‑channel skew of 16 ps in asynchronous mode, and an 86 mA supply current. The devices support both synchronous operation with an external clock and asynchronous operation controlled by the SEL input, with an enable pin to force all outputs low.
Electrical specifications include a supply voltage range of 2.375 V to 5.5 V, operation from –40 °C to +85 °C, and availability in space‑saving 32‑pin 5 mm × 5 mm TQFP and 32‑lead 5 mm × 5 mm QFN packages. Pin configurations provide various input and output terminations, including integrated 50 Ω series outputs for MAX9402/MAX9405 and 100 Ω differential input termination for MAX9403/MAX9405.
| Propagation Delay | 335 ps |
|---|---|
| Channel‑to‑Channel Skew (asynchronous) | 16 ps |
| Supply Voltage Range (VCC‑VEE) | 2.375 V to 5.5 V |
| Supply Current | 86 mA |
| Operating Temperature Range | -40 °C to +85 °C |
| Package Types | 32‑pin 5 mm×5 mm TQFP and 32‑lead 5 mm×5 mm QFN |
The devices have an ultra‑low propagation delay of 335 ps.
They operate with a supply voltage (VCC‑VEE) from 2.375 V to 5.5 V.
They are available in 32‑pin 5 mm×5 mm TQFP and 32‑lead 5 mm×5 mm QFN packages.
