IDT49FCT805BT/CT is a fast CMOS buffer/clock driver from IDT. It is built using 0.5 micron CMOS technology and has low jitter, low power consumption, TTL compatibility, etc. It can be used in commercial and military temperature ranges.
The IDT49FCT805BT/CT is a fast CMOS buffer/clock driver built on 0.5 µm dual‑metal CMOS technology. It offers guaranteed low skew (< 500 ps), very low duty‑cycle distortion (< 600 ps), and high output drive of –32 mA to +48 mA. The device includes two independent output banks with 3‑state control and a heartbeat monitor output for diagnostics.
The datasheet provides detailed pin configurations, absolute maximum ratings, electrical and power‑supply characteristics, and switching performance for both commercial (0 °C to +70 °C) and military (‑55 °C to +125 °C) temperature ranges. It also lists available package types (QSOP, SOIC, SSOP, CERDIP, LCC) and ordering information for the 805BT and 805CT variants.
| Low skew | < 500 ps (max) |
|---|---|
| Duty‑cycle distortion | < 600 ps (max) |
| Output drive current | -32 mA to +48 mA |
| Quiescent power‑supply current | 1.2 mA typical |
The device guarantees a low skew of less than 500 ps (maximum).
It can source up to +48 mA and sink up to –32 mA per output.
Commercial packages: QSOP, SOIC, SSOP; Military packages: CERDIP, LCC.
Commercial: 0 °C to +70 °C; Military: –55 °C to +125 °C.
