SN74HC367N/D/DT/NSR/PW/PWR/PWT/J/W/FK is a 3-state output, high current driving capacity, low power buffer and line driver produced by Texas Instruments. Its operating voltage range is 2V~6V, the output current can reach ±6mA, and it can drive buses, buffer memory address registers, and drive 15 LSTTL loads.
The SN54HC367 and SN74HC367 are hex buffers and line drivers with 3‑state outputs, designed for high‑current drive and low power consumption. They are available in multiple package types and support a wide operating voltage range of 2 V to 6 V.
The document includes ordering information, package options, detailed electrical and switching characteristics, recommended operating conditions, and an important notice about product availability and warranty.
| Supply voltage range | 2 V to 6 V |
|---|---|
| Typical propagation delay | 10 ns |
| Operating temperature range | -40 °C to 125 °C |
The devices operate from 2 V to 6 V supply voltage.
SN54HC367 is offered in CDIP, LOCC, TSSOP, and other package types such as PDIP and SOIC.
