The ANSMANN 8194048 is a compact AC/DC adaptor designed for medical equipment. It accepts a wide input voltage range of 100‑240 V AC at 50/60 Hz and delivers a regulated 9.5 V DC output with a maximum current of 400 mA.
The unit complies with medical safety standards (CE, EN 60601) and features primary and secondary protection, IP20 enclosure rating, and operating temperature from 0 °C to 40 °C. It is supplied in a white folding box with the part number 8194048 printed on the case. This manual is written in German.
| Input voltage | 100‑240 V AC, 50/60 Hz |
|---|---|
| Output voltage (no load) | max 9.5 V DC |
| Output current | 400 mA |
| Power consumption (idle) | < 0.3 W |
| Certifications | CE, conforms to EN 60601 |
It accepts 100‑240 V AC at 50/60 Hz.
The output voltage is up to 9.5 V DC.
The nominal output current is 400 mA.
Yes, it is CE marked and conforms to EN 60601.
