This manual covers the safe installation and operation of the ANSMANN LC8 4-5 Li‑ion battery charger. It lists the required input voltage range, output parameters, LED status indicators, and compliance with relevant safety standards.
Key sections include safety warnings, technical specifications, wiring diagrams, and step‑by‑step operating procedures. The charger is intended for indoor use only and complies with EC/EN 60335‑1 and EC/EN 60335‑2‑29 standards.
| Input Voltage | 100‑240 V 50/60 Hz 900 mA |
|---|---|
| Output Voltage | 14.8 V |
| Output Current | 5 A (5000 mA) |
| Maximum Power | 74 W |
| Dimensions | ≈115 × 60 × 220 mm |
| Compliance | EC/EN 60335‑1, EC/EN 60335‑2‑29 |
| Intended Use | Indoor only |
The charger accepts an input voltage of 100‑240 V at 50/60 Hz.
It delivers a regulated 14.8 V output with a maximum current of 5 A.
No, it is specified for indoor use only.
The device complies with EC/EN 60335‑1 and EC/EN 60335‑2‑29 standards.
