This document provides detailed specifications and features of ASRock Z77 Pro4-M Intel® Z77 chipset, including supported processors and graphics cards, display output options, high-fidelity audio capabilities, and networking features.
This manual covers the Z77 Pro4-M motherboard’s hardware specifications, including supported processors, memory types, expansion slots, storage interfaces, and audio features. It also details BIOS functions, power‑saving technologies, and bundled software utilities.
Key sections describe the board’s form factor, supported Intel 3rd‑generation Core CPUs, dual‑channel DDR3‑2800+ memory, PCIe 3.0/2.0 slots, SATA3/2 ports, USB 3.0 connectivity, and integrated Realtek ALC892 7.1‑channel audio. Installation guidance and troubleshooting tips are provided for end users. This manual is written in Chinese.
| Form factor | Micro ATX 9.6" x 9.6" (244 mm x 244 mm) |
|---|---|
| Memory type | Dual‑channel DDR3 up to 2800+ MHz (OC) |
It supports dual‑channel DDR3 memory up to 2800 MHz (over‑clocked).
The motherboard provides four SATA3 ports.
