ASRock H77M motherboard manual, introduces the specifications, functions, usage methods of the motherboard
This manual introduces the ASRock H77M Micro‑ATX motherboard, detailing its CPU socket (LGA1155), memory support, expansion slots, integrated graphics, audio, LAN, and storage interfaces. It also lists the rear panel I/O connectors and power connections.
Additional sections cover BIOS features, the Instant Flash utility for BIOS updates, jumper settings, and various utilities such as the Extreme Tuning Utility and SmartView. The document includes diagrams and tables for proper installation and configuration. This manual is written in Chinese.
| Form factor | Micro ATX (9.6 in x 8.5 in, 24.4 cm x 21.6 cm) |
|---|---|
| CPU socket | LGA1155 |
| LAN | Gigabit Ethernet (10/100/1000 Mbps) |
| Power connectors | 24‑pin ATX, 8‑pin 12 V |
It uses an LGA1155 socket.
