The GY‑HM700U is a shoulder‑mount HD camcorder that records native QuickTime MOV files for Final Cut Pro and MP4 files for other editing systems. It uses twin SDHC Class 6 cards (or optional SxS cards) for continuous recording, with hot‑swap capability and automatic card switching.
The guide covers the camcorder’s 14× Canon HD lens, 3‑chip progressive CCD sensor, 4.3‑inch LCD monitor, LCOS viewfinder, focus‑assist system, audio inputs (XLR, shotgun mic), and extensive control layout. It also details specifications, optional accessories, and software tools for transferring and managing footage.
| Audio format | 2‑channel 16‑bit/48 kHz LPCM |
|---|---|
| Power consumption (recording) | Approx. 23 W |
| Weight | Approx. 3.4 kg (7.5 lb) |
The camcorder has two twin SDHC card slots that automatically switch when one card fills, allowing continuous shooting.
Yes, with the optional SxS media recorder you can record simultaneously to both SDHC and SxS cards.
It comes with a 14× Canon HD lens featuring a focal range of 4.4 mm to 61.6 mm (35 mm equivalent 32 mm–448 mm).
