VR-N1600 is a high-performance 16-channel network video recorder that can be used in a large-scale surveillance system. It’s an ideal solution for users who want advanced, more versatile network monitoring and enhanced system reliability. Milestone XProtect Enterprise, which holds a major share in this market, is pre-installed, so advanced functions are ready for your commands from day one and all basic operations are possible on this VCR-like front panel. All-in-one design including Reliability, Usability, Scalability – Count on All the Elements to Boost Your Security to New Levels
The VR‑N1600 is a high‑performance 16‑channel network video recorder designed for large‑scale surveillance systems. It features an all‑in‑one design with live viewing, recording, and playback, a VCR‑like front panel, and pre‑installed Milestone XProtect Enterprise software for immediate advanced functionality.
The manual covers front‑panel controls, PTZ camera operation, hard‑disk and NAS storage options, system integration via an open platform, and detailed technical specifications. It also includes installation guidance, network configuration, and troubleshooting information to help users set up and maintain the recorder efficiently.
| Recording format | Motion JPEG / MPEG4 |
|---|---|
| Camera channels | 16 |
| Frame rate (VGA) Recording/Display/Distribution | 160/80/80 fps |
| CPU | Core 2 Duo E4300 (1.80 GHz) |
| RAM | 512 MB (1 GB recommended) |
| Internal HDD capacity | 500 GB (expandable to 5 TB) |
| Maximum internal HDD | 4 TB (USB external) |
| NAS support | Yes |
| RAID | Hardware RAID1 (mirroring) |
| Audio interface | 2‑channel |
| Power supply | AC 120 V (U) / AC 220‑240 V (E) |
| Operating temperature | 5 °C – 40 °C |
| Weight | 7.7 kg (17 lb) |
The VR‑N1600 supports up to 16 camera channels.
Yes, the recorder includes NAS archive capability for high‑capacity recording and mirroring.
