The S8VS is a switch mode power supply launched by Panasonic. It has 15/30-W, 60/90/120/180/240-W models.
The S8VS series is a compact, thin‑profile switch mode power supply designed for flexible mounting in control panels. It measures 22.5 × 85 × 96.5 mm (W × H × D) and supports three mounting directions, including DIN‑rail installation, with lead‑free solder connections. The units meet safety standards such as UL508, CSA C22.2 No. 14, EN50178 and EN60950‑1.
The manual lists the full range of ratings, from 15 W to 240 W, with output voltages of 5 V, 12 V or 24 V. It details efficiency values, inrush current, protection features (overload, over‑voltage, undervoltage alarm), and optional monitoring functions like maintenance‑forecast or total‑run‑time monitors. Environmental limits, dimensions, weight, and EMI compliance are also provided.
| Input Voltage | 100 to 240 VAC (85 to 264 VAC) |
|---|---|
| Output Voltage Options | 5 V, 12 V, 24 V |
| Typical Efficiency (5‑V models) | 72% min. (76% typ.) |
| Dimensions (W × H × D) | 22.5 × 85 × 96.5 mm |
| Weight | 160 g max. |
| Mounting | DIN‑rail, panel mounting, three directions |
The S8VS accepts an input voltage from 100 to 240 VAC (85 to 264 VAC).
The series provides output voltages of 5 V, 12 V, or 24 V.
Yes, the unit is designed for DIN‑rail mounting as well as panel mounting in three directions.
