This user guide introduces the features and characteristics of TL-SG1008/TL-SG1016/TL-SG1024 8/16/24-port Gigabit Ethernet Switch.
This guide introduces the TL‑SG1008, TL‑SG1016 and TL‑SG1024 8/16/24‑port Gigabit Ethernet switches, describing their features such as non‑blocking switching architecture, auto‑MDI/MDIX, and LED status indicators. It explains how the switches comply with IEEE802.3 standards and support auto‑negotiation for 10/100/1000 Mbps operation.
The manual covers mounting the switch on a desk or in a 19‑inch rack, power‑on procedures, front‑ and rear‑panel identification, LED meanings, technical specifications, and troubleshooting steps for common issues like power or link LED failures. This manual is written in Chinese.
| Number of Ports | 8 / 16 / 24 |
|---|---|
| Port Speed | 10/100/1000 Mbps Auto‑Negotation RJ‑45 ports |
| Power Input | 100‑240 V~ 50‑60 Hz 0.6 A |
| Data Transfer Rate (Gigabit) | 2000 Mbps Full‑Duplex |
Attach the four rubber footpads to the bottom of the switch and place it on a flat surface; the desk can support up to 5 kg on top.
Verify that the AC power cord is properly connected to the switch and that the power source is turned on.
