AXOJUMP® Flat Flexible Cables consist of flat tin plated copper conductors insulated between Polyester based tapes. Depending on the type of interconnection used, reinforcement tapes can be added to the cable ends to allow for connector compatibility. It also introduces different types of reinforcement tapes and the characteristics of pre-stripping.
Axojump® flat flexible cables are flat tin‑plated copper conductors insulated with polyester‑based tapes. Various reinforcement options are offered, including standard polyester tapes, polyimide tapes, pull‑up adhesive tape, easy‑to‑insert tape, and pre‑stripping for transport protection.
The document provides detailed technical data such as pitch, conductor count, dimensions, UL style voltage ratings, and temperature limits down to –40 °C. It also lists typical applications like board‑to‑board interconnections in CD players, printers, laptops, LCD displays, car radios, TVs, and satellite receivers.
| Pitch range | 0.50 mm – 2.54 mm |
|---|---|
| Conductor width | 0.30 mm – 1.57 mm |
| Minimum operating temperature | –40 °C |
They are used for board‑to‑board interconnections in CD players, VCRs, printers, laptops, LCD displays, car radios, TVs, telephones, fax machines, hi‑fi equipment, satellite receivers and decoders.
The cables are guaranteed to operate down to –40 °C.
