This document is a manual for an OSRAM LED light, which is a SMT-LED with multiple colors. It can be used as a SIDELED® , Mini SIDELED® , Power TOPLED® , Smart LED , Mini TOPLED® , CHIPLED 1206 , CHIPLED 0603 , CHIPLED 0805 , SMT-LED SOT-23 , TOPLED® and Multi TOPLED®.
The document provides the type designation system for Osram SMT LEDs, describing color codes, wavelength ranges and package types such as SIDELED®, TOPLED® and CHIPLED®. It also details the packaging options, including 8 mm and 12 mm tape‑and‑reel formats with specific piece counts per reel.
Safety instructions reference IEC 825‑1 and EN 60825‑1 standards and outline the recommended operating range to achieve a lifetime of over 10⁵ hours. The luminous intensity grouping system is explained, showing how LEDs are measured in half‑groups with a maximum intensity variation of less than 1.6. This manual is written in German.
